HCFH SERIES | |||
| Product number | HCFH SERIES | |
| manufacturer | HUASUN | ||
| PID | |||
| shipping method | Self-operated | ||
| product life | In mass production | ||
| RoHs & lead-free situation | Lead-free/RoHs compliant | ||
| describe | Excellent price, good quality, wide range of values, and good reliability. | ||
HCFH SERIES naming convention | |||
 | |||
(1) | Type | ||
(2) | Dimensions | ||
(3) | Internal code | ||
(4) | Inductance | ||
| (5) | Inductance Tolerance | ||
| K: ±10% L: ±15% M:±20% | |||
HCFH SERIES appearance dimensions In mm | |||||
 | TYPE | A | B | C | D |
| HCFH160808 | 1.6±0.20 | 0.80±0.20 | 0.80±0.20 | 0.3±0.20 | |
| HCFH201209 | 2.0±0.20 | 1.20±0.20 | 0.90±0.20 | 0.5±0.30 | |
| HCFH252010 | 2.5±0.20 | 2.0±0.20 | 1.00±0.20 | 0.5±0.30 | |
| HCFH160808 series Standard Specifications | ||||||
| Part No. | Inductance | Test Freq. | DCR(Ω) | SRF(MHz) | Rated current | Tolerance |
| (μH) | (MHz) | ±30% | Min | (mA)Max | (±%) | |
| HCFH160808B-R56□ | 0.56 | 1 | 0.12 | 100 | 1050 | 20 |
| HCFH160808B-1R0□ | 1 | 1 | 0.2 | 98 | 900 | 20 |
| HCFH160808B-1R8□ | 1.8 | 1 | 0.24 | 95 | 750 | 20 |
| HCFH160808B-2R2□ | 2.2 | 1 | 0.24 | 95 | 750 | 20 |
| HCFH160808B-4R7□ | 4.7 | 1 | 0.5 | 65 | 700 | 20 |
| HCFH201209A-1R0□ | 1 | 1 | 0.14 | 75 | 300 | 20 |
| HCFH201209A-2R2□ | 2.2 | 1 | 0.224 | 50 | 220 | 20 |
| HCFH201209A-3R3□ | 3.3 | 1 | 0.24 | 35 | 200 | 20 |
| HCFH201209A-4R7□ | 4.7 | 1 | 0.3 | 25 | 180 | 20 |
| HCFH201209B-1R0□ | 1 | 1 | 0.11 | 75 | 1150 | 20 |
| HCFH201209B-2R2□ | 2.2 | 1 | 0.2 | 50 | 950 | 20 |
| HCFH201209B-3R3□ | 3.3 | 1 | 0.22 | 35 | 800 | 20 |
| HCFH201209B-4R7□ | 4.7 | 1 | 0.3 | 25 | 750 | 20 |
| HCFH201209B-6R8□ | 6.8 | 1 | 0.35 | 25 | 600 | 20 |
| HCFH252010A-1R0□ | 1 | 1 | 0.08 | 70 | 400 | 20 |
| HCFH252010A-2R2□ | 2.2 | 1 | 0.12 | 55 | 300 | 20 |
| HCFH252010A-3R3□ | 3.3 | 1 | 0.144 | 30 | 260 | 20 |
| HCFH252010A-4R7□ | 4.7 | 1 | 0.18 | 25 | 240 | 20 |
| HCFH252010B-1R0□ | 1 | 1 | 0.06 | 70 | 1600 | 20 |
| HCFH252010B-2R2□ | 2.2 | 1 | 0.1 | 55 | 1300 | 20 |
| HCFH252010B-3R3□ | 3.3 | 1 | 0.14 | 30 | 1200 | 20 |
| HCFH252010B-4R7□ | 4.7 | 1 | 0.18 | 25 | 1100 | 20 |
