HCPK SERIES

application:
switching circuit
Operational Amplifier
electronic product

Features:
Affordable
Wide range of inductors
High reliability

Quantity:
Availability:





Inquire Add to Basket

Product Description

HCPK0406 series Standard Specifications
Part No.	Inductance (μH)	Test Freq.	Q Min	DCR(Ω) Max	Isat(mA) Max
Part No.	Inductance (μH)	Test Freq.	Q Min	DCR(Ω) Max	Isat(mA) Max
HCPK0406-1R0□	1.0	7.96MHz	50	0.150	300
HCPK0406-1R2□	1.2	7.96MHz	50	0.150	300
HCPK0406-1R5□	1.5	7.96MHz	55	0.200	300
HCPK0406-1R8□	1.8	7.96MHz	70	0.200	300
HCPK0406-2R2□	2.2	7.96MHz	75	0.250	300
HCPK0406-2R7□	2.7	7.96MHz	80	0.250	300
HCPK0406-3R3□	3.3	7.96MHz	80	0.250	300
HCPK0406-3R9□	3.9	7.96MHz	80	0.300	300
HCPK0406-4R7□	4.7	7.96MHz	75	0.300	300
HCPK0406-5R6□	5.6	7.96MHz	75	0.350	300
HCPK0406-6R8□	6.8	7.96MHz	70	0.350	300
HCPK0406-8R2□	8.2	7.96MHz	70	0.350	300
HCPK0406-100□	10	2.52MHz	80	0.600	200
HCPK0406-120□	12	2.52MHz	80	0.650	200
HCPK0406-150□	15	2.52MHz	80	0.750	200
HCPK0406-180□	18	2.52MHz	75	0.850	200
HCPK0406-220□	22	2.52MHz	75	1.000	200
HCPK0406-270□	27	2.52MHz	75	1.200	200
HCPK0406-330□	33	2.52MHz	75	1.300	200
HCPK0406-390□	39	2.52MHz	70	1.500	200
HCPK0406-470□	47	2.52MHz	70	1.600	200
HCPK0406-560□	56	2.52MHz	65	1.650	200
HCPK0406-680□	68	2.52MHz	60	1.800	200
HCPK0406-820□	82	2.52MHz	55	1.850	200
HCPK0406-101□	100	0.796MHz	80	2.000	200
HCPK0406-121□	120	0.796MHz	80	2.500	100
HCPK0406-151□	150	0.796MHz	80	3.000	100
HCPK0406-181□	180	0.796MHz	75	3.500	100
HCPK0406-221□	220	0.796MHz	75	4.000	100
HCPK0406-271□	270	0.796MHz	70	5.000	50
HCPK0406-331□	330	0.796MHz	70	6.000	50
HCPK0406-391□	390	0.796MHz	70	6.500	50
HCPK0406-471□	470	0.796MHz	70	7.500	50
HCPK0406-561□	560	0.796MHz	70	8.000	50
HCPK0406-681□	680	0.796MHz	70	8.500	50
HCPK0406-821□	820	0.796MHz	70	9.500	50
NOTE: □-Tolerance M=±20% / T=±30%/K=±10%
1.Operating temperature range -25℃～8５℃(Including self-temperature rise)
2.Isat for Inductance drop 10% from its value without current.
